• C2060 Conveyor Chain is a heavy-duty double-pitch roller chain designed for industrial conveyor and material handling systems that require increased strength and load capacity. With a longer pitch than standard roller chain, the C2060 reduces chain weight and the number of links per foot while maintaining durability for low-speed conveying applications.

  Manufactured to ANSI B29.4 standards, this chain is commonly used in heavy material handling, pallet conveyors, and industrial processing lines.

  ---

  🛠 Key Features

  • Chain Size: C2060 double-pitch conveyor chain

  • Pitch: 1.50″ double pitch spacing

  • Length: 10 ft roll

  • ANSI Standard: B29.4 compliant

  • Material: Heat-treated carbon steel

  • Solid Rollers: Smooth engagement and extended service life

  • Pre-Lubricated: Ready for installation

  • High Load Capacity: Designed for heavier conveyor applications

  ---

  📏 Specifications

  Attribute	Value
  Chain Size	C2060
  Chain Type	Double Pitch Roller Chain
  Pitch (P)	1.50″
  Inner Width (b1)	1/2″
  Roller Diameter (d1)	0.469″
  Pin Diameter (d2)	0.234″
  Plate Thickness	Approx. 0.094″
  Average Tensile Strength	~10,000 lbs
  Max Working Load	~1,800 lbs
  Standard	ANSI B29.4

Supplied as one 10 ft boxed roll
